16
Add fuses to the following
wires (wire with inline fuses
crimped in place).
• Alternator Field
• Alternator V+
• Battery V+
Carefully crimp all wires and
verify that it matches the
diagram.
Verify all the pins in the wiring
harness using a multi meter.
Click NEXT
to continue.
Click NEXT
to continue.
Click NEXT
to continue.
3
4
5
INSTALLATION
16
