Cover Plate Instructions:
With notches facing up, slide one side of
cover plate into guide clip. Align notches
and push other side of cover plate into
guide clip. Cover plate will click into place.
Center Section Instructions:
Slide A-D filter and inside cover plate into
Filter Holder. Slide notches on top of Filter
Holder into slots on helmet. Line up Filter
Holder with Centering Pin on helmet, squeeze
tabs on Filter Holder and push into tab slots.
Release tabs into bottom catches.
Slots
Centering
Pin
Bottom
Catch
PYTHON
®
06-HG
06-HGSB
I
nside Cover Plate
(see Table 1)*
A
uto-Darkening Filter
P
YTHON-911-S
Python 90x110 Shell
PYTHON01-911-CP
Python 90x110 Cover Plate
PYTHON01-911-CS
Python 90x110 Center Section
Guide Clip
PYTHON01-911-CP
Python 90 X 110 Cover Plate
*Optional Mag Lens,
V
ML-XXX, Where
XXX=Diopter number
(Not shown)
To Next Page
