ArcOne 1000FcF - Filter Specifications

- 8-
1000FcF 1500V 2000V 2500V 4000V 4500V iDF48
Viewing Area
3864 mm
2
(6.0 sq in)
3864 mm
2
(6.0 sq in)
4704 mm
2
(7.3 sq in)
4704 mm
2
(7.3 sq in)
4500 mm
2
(7.0 sq in)
4500 mm
2
(7.0 sq in)
4608 mm
2
(7.1 sq in)
Filter Size 90x110 mm 90x110 mm 90x110 mm 90x110 mm 90x110 mm 90x110 mm 90x110 mm
ARC
Sensing
Two
sensors
Two
sensors
Two
sensors
Two
sensors
Four
sensors
Four
sensors
Two
Sensors
Sensitivity
Control
Analog:
Variable
Analog:
Variable
Analog:
Variable
Analog:
Variable
Analog:
Variable
Digital:
Variable
Digital:
Variable
Switching
Time
(seconds)
1/10,000
(0.1 msec)
5/10,000
(0.5 msec)
5/10,000
(0.5 msec)
1/10,000
(0.1 msec)
1/10,000
(0.1 msec)
1/10,000
(0.1 msec)
1/10,000
(0.1 msec)
Primary
Power
Solar Cells Solar Cells Solar Cells Solar Cells
Lithium
Battery &
Solar Cells
Lithium
Battery &
Solar Cells
AA
Battery &
Solar Cells
Back-up
Power
Lithium
Battery
Lithium
Battery
Lithium
Battery
Lithium
Battery
Lithium
Battery
Lithium
Battery
Lithium
Battery
Operating
Temp.
-10-55C
(14-131F)
-10-55C
(14-131F)
-10-55C
(14-131F)
-10-55C
(14-131F)
-10-55C
(14-131F)
-10-55C
(14-131F)
-10-55C
(14-131F)
Storage
Temp.
-10-38C
(14-100F)
-10-38C
(14-100F)
-10-38C
(14-100F)
-10-38C
(14-100F)
-10-38C
(14-100F)
-10-38C
(14-100F)
-10-38C
(14-100F)
UV / IR
Protection
Up to Shade
16
Up to Shade
16
Up to Shade
16
Up to Shade
16
Up to Shade
16
Up to Shade
16
Up to Shade
16
Dark to Light
Delay
0.2- 2
seconds
0.2-2
seconds
0.2-2
seconds
0.2-2
seconds
0.1-2
seconds
0.1-2
seconds
0.1-3.5
seconds
Light Shade 4 4 4 4 4 4 4
Dark Shade 9-13 9-13 9-13
9-13 9-13 9-13 5-8/9-13
Grind Mode Yes No No No Yes Yes Yes
Intelligent
Auto-Shade
Mode
No No No
No No No Yes
Intelligent
TIG Mode
No No No No No No Yes
Enclosure
Integrity
Not Dust/Water
Resistant
Not Dust/Water
Resistant
Not Dust/Water
Resistant
Not Dust/Water
Resistant
Not Dust/Water
Resistant
Not Dust/Water
Resistant
Dust/Water
Resistant
Standards
4
CE EN379
4
CE EN379
4
CE EN379
4
CE EN379
4
CE EN379
2
CE EN379
2
CE EN379
Optical Class 111
1111
Diffusion of
Light Class
2 2 2 2 1 1 1
Variation in
Luminous
Transmit-
tance Class
111
1111
Angle
Dependency
Class
3 3 3 3 2 2 2
Inside Cover
Plate Part
Numbers
03-OP 09-IP 03-OP 03-OP 03-OP 03-OP 04-OP
Table 1. Filter Specifications
