Explosion diagram 4
Number
Name
Number
Name
Number
Name
401
Folding buckle
402
9X1X40 compression
spring
403
Folding Buckle
Positioner
404
3X12 pan head
self-tapping screws
405
Chassis cover
406
4X20 pan head
self-tapping screws
407
4X20 pan head
self-tapping screws
408
Suction Motor Noise
Cover 2
409
3X30 pan head
self-tapping screws
410
Electromagnetic valve
411
4X12 pan head
self-tapping screws
412
Water pipe
413
6.3 water pipe quick
connector
414
M6X40 cylinder head
screw
415
ф40X23 wheel
