Arcora BLANCUS 40 - Page 15

15
416
M6 fasten the screw
nut
417
Host shell
418
LED light
419
LED light nut
420
3X8 Pan head
self-tapping screws
421
Main control circuit
board
422
M3 nut
423
Charging socket
424
M3X12 countersunk
head screw
425
3X16 pan head
self-tapping screws
426
Suction Motor Mount
427
Suction motor
428
O-ring 14 (inner)X2.5
429
Suction Motor Noise
Cover 1
430
Explosion diagram 5
Number
Name
Number
Name
501
Left thread brush motor
502
M6X25、20 countersunk
head screw
