1-3
1
* w/Blue Loctite #243
** w/Red Loctite #271
*** w/Green Loctite #609
Torque Conversions
(ft-lb/N-m)
DRIVE TRAIN COMPONENTS
Part Part Bolted To
Torque
ft-lb N-m
Engine Mounting Through-Bolt Frame 38 52
Front Differential Frame/Differential
Bracket
38 52
Output Flange Rear Flange Output Joint 20 27
Input Shaft Housing Differential Housing 18 25
Pinion Housing Gear Case Housing 18 25
Differential Housing Cover*** Differential Housing 18 25
Drive Bevel Gear Nut** Shaft 59 80
Driven Bevel Gear Nut** Driven Shaft 59 80
Thrust Button Gear Case Cover 8 11
Hub Nut Shaft/Axle (max) 200 272
Oil Drain Plug Front Differential/Rear
Drive
45
in.-
lb
5
Oil Fill Plug Front Differential/Rear
Drive
16 22
Oil Drain Plug Engine 20 27
Rear Drive Input Shaft Hous-
ing
Differential Housing 23 31
Lock Collar Differential Housing 125 169
Wheel Hub 40 54
Rear Drive Gear Case Frame 38 52
Engine Output Flange Rear Gear Case Input
Flange
20 27
BRAKE COMPONENTS
Brake Disc* Hub 15 20
Brake Hose Caliper 20 27
Brake Hose Master Cylinder 20 27
Brake Hose Auxiliary Brake Cylinder 20 27
Master Cylinder (Rear) Frame 8 11
Master Cylinder Clamp (Front) Master Cylinder 5.5 8
Hydraulic Caliper Knuckle 20 27
Auxiliary Brake Pedal Pivot 20 27
ft-lb N-m ft-lb N-m ft-lb N-m ft-lb N-m
1 1.4 26 35.4 51 69.4 76 103.4
2 2.7 27 36.7 52 70.7 77 104.7
3 4.1 28 38.1 53 72.1 78 106.1
4 5.4 29 39.4 54 73.4 79 107.4
5 6.8 30 40.8 55 74.8 80 108.8
6 8.2 31 42.2 56 76.2 81 110.2
7 9.5 32 43.5 57 77.5 82 111.5
8 10.9 33 44.9 58 78.9 83 112.9
9 12.2 34 46.2 59 80.2 84 114.2
10 13.6 35 47.6 60 81.6 85 115.6
11 15 36 49 61 83 86 117
12 16.3 37 50.3 62 84.3 87 118.3
13 17.7 38 51.7 63 85.7 88 119.7
14 19 39 53 64 87 89 121
15 20.4 40 54.4 65 88.4 90 122.4
16 21.8 41 55.8 66 89.8 91 123.8
17 23.1 42 57.1 67 91.1 92 125.1
18 24.5 43 58.5 68 92.5 93 126.5
19 25.8 44 59.8 69 93.8 94 127.8
20 27.2 45 61.2 70 95.2 95 129.2
21 28.6 46 62.6 71 96.6 96 130.6
22 29.9 47 63.9 72 97.9 97 131.9
23 31.3 48 65.3 73 99.3 98 133.3
24 32.6 49 66.6 74 100.6 99 134.6
25 34 50 68 75 102 100 136
