This product is intented for household use ONLY and not for commercial
/ industrial or outdoor use.
The appliance must be installed by professionally qualified personnel.
1. Screw terminal
2. Support rod
3. Electric cables
4. Upper cap
5. Screw for fixing the upper cap
6. Lower cap
7. Pin for fix the support rod
8. Pin’s nut (n. 7)
9. Motor support
10. Motor
11. Control unit
12. Screws and washers for securing the
blades (fixed on the motor housing)
13. Blade
