ARDES AR5A90L - Technical Information and Components; Component Identification

12
Technical informations
1. Screw terminal
2. Support rod
3. Electric cables
4. Upper cap
5. Screw for fixing the upper cap
6. Lower cap
7. Pin for fix the support rod
8. Pin’s nut (n. 7)
9. Motor support
10. Motor
11. Control unit
12. Screws and washers for securing
the blades (fixed on the motor housing)
13. Blade
14. Decorative glass
1
2
3
4
5
6
7
8
9
10
11
12
13
14
