ARDES AR5M40 - Technical Informations

12 34
567 8
9 10
11
12
13
14
15
16
17
18
19
20
21
22
23
16
17
18
24
25
Technical informations
14
1 - Safety screw
2 - Lock ring
3 - Misting adjustment knob
4 - Front grille
5 - Fan lock ring
6 - Fan
7 - Back grille lock ring
8 - Back grille
9 - Motor shaft
10 - Motor
11 - Misting tube
12 - Control panel
13 - Main body
14 - Main body screw
15 - Power cord
16 - Supporting tubes
17 - Base
18 - Base weight
19 - Humidier power cord
20 - Humidier cap
21 - Humidier tank
22 - Humidier main body
23 - Humidier control panel
24 - Fixing plate
25 - Screws and washers
