ARDES AR5M41 - Technical Informations

16
Technical informations
GB
1. Mist plate
2. Front grille
3. Fixing mist plate screw (3 pcs.)
4. Lock ring of the fan
5. Fan
6. Lock ring of the back grille
7. Back grille
8. Motor shaft
9. Front cover of the motor
10. Back cover of the motor
11. Connector
12. Connector bracket
13. Support pole
14. Fastening screw
15. Main body (rear shell)
16. Water tank
17. Water drain and stopper
18. Base
19. Lock ring of the base
20. Wheels (5 pcs.)
21. Locking ring
22. Mist tube
23. Control panel
24. Remote control
25. Main body (front shell)
26. Light indicator of water in the
tank
1 2 3 4 5 6 7 8 9 10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
If the fan must be stored for a long period and is not used regularly, place
the fan in its original packaging in a dry place. When you use it for the
rst time after a long period of inactivity, make sure the fan is clean and
the motor blades turn feely (with the device not powered) without any
restraint.
