Arduino Portenta H7

Arduino® Portenta H7
11 / 25 Arduino® Portenta H7 / Rev. 01 - 25/11/2021
3.4 Power Consumption
Symbol Description Min Typ Max Unit
PBL Power consumption with busy loop TBC mW
PLP Power consumption in low power mode TBC mW
PMAX Maximum Power Consumption TBC mW
4 Functional Overview
4.1 Board Topology
Board Topology TOP side
Board Topology BOTTOM side
