Arduino® Portenta H7
2 / 25 Arduino® Portenta H7 / Rev. 01 - 25/11/2021
1 Configuration Options and Ordering Codes
Available assembly options that can be configured for high volume applications are the following:
Option Description Option Codes
SDRAM external SDRAM memory 0 - None1 - 8 MByte2 - 16 MByte3 - 32 MByte4 - 64 MByte
FLASH external QSPI Flash Memory 0 - None1 - 2 MByte (NOR)5 - 16 MByte (NOR)8 - 128 MByte (NAND)
Ethernet 10/100 Ethernet PHY 0 - NoneE - Fitted
HS USB High Speed USB PHY 0 - NoneU - Fitted
Crypto Crypto Chip 0 - NoneM - ATECC608AN - SE050C2B - Both
Wireless Wireless Module 0 - NoneW - Fitted
Antenna Antenna option 0 - NoneA - on board ceramic antennaC - U.FL connector
Video DisplayPort output over USB-C 0 - NoneD - Fitted
Standard configurations are:
Arduino Portenta H7-0000000 (barebones version)
Arduino Portenta H7-15EUCWAD
8MB SDRAM
16MB NOR Flash
10/100 Ethernet Phy
USB HS
NXP SE050C2 Crypto
Wi-Fi/BT Module
U.FL Antenna
DisplayPort over USB-C
Target Areas

Arduino Portenta H7 Specifications

General

Clock Speed	480 MHz (Cortex-M7), 240 MHz (Cortex-M4)
Operating Voltage	3.3V
Analog Output Pins	2
CAN	2
SD Card	Yes
Flash Memory	2 MB
SRAM	1 MB
Core	Dual-core ARM Cortex-M7 + M4
Input Voltage	5V
UART	4
SPI	3
I2C	3
Ethernet	Yes
USB	USB 2.0
Wi-Fi	802.11b/g/n
Bluetooth	Bluetooth 5.1
Camera Interface	Yes
Display Interface	Yes
External Memory	Yes
Connectors	High-Density Connectors (2x 80-pin)
Dimensions	66 mm x 25.4 mm
Processor	STM32H747
