2× operational amplifiers (7.3 MHz bandwidth)
1× digital filters for sigma delta modulator (DFSDM) with 8 channels/4 filters
Graphics
MIPI DSI host including an MIPI D-PHY to interface with low-pin count large displays
Chrom-ART graphical hardware Accelerator™ (DMA2D) to reduce CPU load
Hardware JPEG Codec
Up to 22 timers and watchdogs
1× high-resolution timer (2.1 ns max resolution)
2× 32-bit timers with up to 4 IC/OC/PWM or pulse counter and quadrature (incremental) encoder input (up
to 240 MHz)
2× 16-bit advanced motor control timers (up to 240 MHz)
10× 16-bit general-purpose timers (up to 240 MHz)
5× 16-bit low-power timers (up to 240 MHz)
4× watchdogs (independent and window)
2× SysTick timers
RTC with sub-second accuracy and hardware calendar
True random number generators (3 oscillators each)
96-bit unique ID
External Memories
up to 64 MByte SDRAM (optional)
up to 128 MByte QSPI Flash (optional)
USB-C
High Speed (optional)/Full Speed USB
DisplayPort output (optional)
Host and Device operation
Power Delivery support (optional)
High Density connectors
1x 10/100 Ethernet with PHY
1x CAN
4x UART (2 with flow control)
3x I2C
1x SDCard
1x SPI
1x I2S
1x PDM input
2 lane MIPI DSI output
8 bit parallel camera interface
10x PWM outputs
7x GPIO
8x ADC inputs with separate VREF
Murata 1DX Wi-Fi/BT Module (optional)
Wi-Fi 802.11b/g/n 65 Mbps
