Propeller Replacement
Should the propeller need replacing, you will need to hold the prop shaft with
a pair of needle nose pliers while you screw the propeller on in a clockwise
direction. Screw the prop onto the shaft until the shaft is ush with the front
of the propeller hub. The propeller should rotate without touching the cowl.
Replacement Parts
AZSB1803 .............70mAh 1-cell/1S 3.7V 10C LiPo with ultra-micro connector
AZSA1806..............3-channel, 3-in-1 control unit – receiver / 2 servos / ESC
AZS1509 ................Motor with pinion gear
AZS1511 ................Gearbox with shaft
AZS1512 ................Propeller shaft with gear
AZS1513 ................Wing set with decals
AZS1514 ................Tail set with decals
AZS1515 ................Fuselage with decals
AZS1516 ................Main landing gear set
AZS1517 ................Pushrod set
AZS1518 ................Wing strut set
AZS1520 ................Decal set
AZSP1522 .............4.7 x 2.75 micro scale propeller
AZSA1838M1 ........Micro 4-channel airplane Tx with 100mA charger (Mode 1)
AZSA1838..............Micro 4-channel airplane Tx with 100mA charger (Mode 2)
AZS1107 ................Replacement rotary servo mechanics
