◼ DELAY_TIME1: Switch to Car Mode to Turn off Delay Time
Switch
1 / 2 / 3
Definition
ON / ON / ON
Shutdown Timer by O.S (Default)
ON / ON / OFF
1 min.
ON / OFF / ON
5 mins.
ON / OFF / OFF
10 mins.
OFF / ON / ON
30 mins.
OFF / ON / OFF
1 hour
OFF / OFF / ON
2 hours
OFF / OFF / OFF
Reserved
◼ Steps to Set the Power Ignition
Step 1: Select the power ignition by PC/CAR switch.
Step 2: To configure the power off delay time, please check the delay time setting options in
advance.
Example: Set the delay time as 1 minute
When the delay time is set as “1 minute”, the system will shut down 1 minute after you turn off
the vehicle engine.
Step 1
Pin 1-2 (Left)：PC Power Mode
Pin 2-3 (Right)：Vehicle Power Ignition Mode
