DXC5K/EN IN/A22 Installation

Page 12/34

DXC 5000

3.2 Connector pin definition and connection

Pin Number Signal Description

1 -V -DC 48 Volts

2 +V +DC Return

Chassis Ground

TABLE 1: POWER CONNECTOR FOR MAIN UNIT

Pin Number Signal Description

1 NC Fuse Relay - Normally Close

2 C Fuse Relay - Common

3 NO Fuse Relay - Normally Open

4 NC Alarm Relay –Normally Close

5 C Alarm Relay –Common

6 NO Alarm Relay –Normally Open

TABLE 2: ALARM RELAY CONNECTOR

The console port is configured as a DCE device with a DB-9 female connector. Pin

definitions and pin connections are listed in Table 2-4 below.

Pin Number Signal Source

1 Data Carrier Detect To DTE

2 Receive Data To DTE

3 Transmit Data From DTE

4 Unassigned

5 Signal Ground

6 Data Set Ready To DTE

7 Unassigned

8 Clear to send To DTE

9 Unassigned

TABLE 3: CONSOLE PORT

SLIP port can be connected via RS232 interface. Pin definition is listed in Table 2-5.

Pin Number Signal Source

1 Data Carrier Detect From DCE

2 Receive Data From DCE

3 Transmit Data To DTE

4 Data Terminal Ready To DTE

5 Signal Ground

TABLE 4: SLIP PORT (9 PIN)
