4. CONFIGURATION SETTING
4.1 Software configuration setting
There are three system configurations:
• Factory default
• Current working
• User stored
Factory default configurations are not changeable. Each DXC 5000 is shipped with all three
configurations set to the factory default configuration.
The current working configuration, which can be saved into nonvolatile memory as a user-
stored configuration, can be changed at any time. When the system is reset, the previous
configuration will be retrieved as the current working configuration. The user-stored
configuration can be retrieved at any time. User can retrieve the user-stored configuration to
overwrite the current working configuration.
4.2 Replacement of Plug-in Card
When a plug-in card is removed and replaced with a card of a different type, default
configuration is assigned to the new card. The user must set the configuration for each
change of card type. If the same type card is inserted, depending on card type, then the
following happens:
• For E1, T1, and DTE plug-in cards, the previous configuration is automatically
downloaded.
• For Router plug-in card, the factory default configuration is assigned to the new card.
• For E1/ T1 ATM Frame Relay plug-in card, (a) The port configuration for E1 or T1 is
automatically downloaded, (b) The Frame Relay management setup is factory default
configuration.
Console Port Fixed
Baud Rate 9600
Data Bit 8
Stop Bit 1
Parity Bit NONE
XON-XOFF OFF
Interface TERMINAL
SNMP OFF
E1 Line Item Default
Line Frame FAS
Line Code HDB3
Interface Card setting
Line FDL OFF
FDL Sa-bit Sa4
Line AIS OFF
Line RAI ON
Line CRC ON
Idle Code 0Xd5
