Installation DXC5K/EN IN/A22
DXC 5000 Page 31/34
T1 Line Item Default
Line Frame ESF
Line Code B8ZS
Interface Long Haul
Line LBO 0dB
Line EQU 0-133 ft
Line AIS OFF
Line YEL ON
Line Inband OFF
Idle Code 0xFF
HDSL Items Default
XDSL MODE Master
CLOCK SOURCE Internal
LINE RATE 768k bps
LINE CODE 2B1Q
DTE (V.35/ V.36/ EIA530/
X.21/V.11) Item
Default
RATE 64K
CLOCK Normal
DATA Normal
RTS Activate
TTM Off
V.54 Off
INTERFACE
(Depend on which DTE card
is plugged into the shelf)
V.35,
V.36,
EIA530/RS449,
X.21/V.11
DTE (X.50) Item Default
X50 MUX NO_MUX
SYNC MODE SYNC
RATE 1.2K
PHASE Fixed
4.8K SEL Fixed
CLOCK Normal
DATA Normal
RTS Permanent
TTM Off
INTERFACE RS-232
WARNING No
