Areva FP 73 - Removal of a Led Pole; Essential Verifications Before Mounting New Pole; Installation of the New Pole

25
First type of pole equipment
 Unclip and lift off the deflector.  Unscrew the 2 fixing bolts, then
remove the upper connector
(13mm spanner).
1.2
The 6x35mm cotter pin and
the positioning
pin remain
fixed on the connector.
Pin
Cotter pin
 Extract the 6x35 cotter pin from
the connector (pin punch and
hammer or flat-nosed pliers).
Cotter pin
Pin punch
 Unscrew the 2 fixing bolts, then
remove the lower connector (13
mm spanner).
1.6
Second type of pole equipment
 Remove the maintaining bolt for
the upper deflector
(5 mm Allen key).
 Remove the deflector.
 Unscrew the 3 fixing bolts, then
remove the upper connector
(16mm spanner).
 Unscrew the fixing bolt then
remove the spacer from the
lower connector
(16 or 17 mm spanner).
