9.1 Accessories
1
2
3
4
Fig. 9.1
Accessories for HVX circuit-breaker
Position Designation Order no.
1 ON/OFF operating rod AGS H35 446-01
2 Spring charging crank for spring operating mechanism AGS H30 498-01
3
Moving crank handle with integrated slip coupling for withdrawable parts in PIX
switchgear panels
AGS H31 642-01
1)
AGS H32 532-01
2)
AGS H31 674-01
3)
4 Moving crank handle for withdrawable parts in PIX high current switchgear panels AGS C66 911-01
9.2 Auxiliary products
Only the following auxiliary products
may be used, which are available
from the manufacturer. The use of
other auxiliary products is not admis-
sible.
Warning!
Danger of injury when
wrong handling the au-
xiliary products. Comply
with the safety data sheets sup-
plied by the manufacturers of
the auxiliary products.
1)
Withdrawable part, manually actuated, shape of insertion opening: hexagonal
2)
Withdrawable part, manually actuated, shape of insertion opening: square
3)
Emergency crank handle for withdrawable part, motor-actuated
Designation Symbol Order no.
Cleaning agent, 1 l can S 008152
Contact lubricant Kontasynth, 0.5 kg can
S 008167
High-pressure grease
ST 312-101-001
Cryogenic grease
ST 312-105-001
Silicon grease
ST 312-504-001
Lubricant KL, 0,5 kg can ST 312-111-835
Liquid lubricant FL, 0,5 kg can S 008153
