4.4.1 Probe Setting
4.4.1.1 Physically, connect Probe to Socket”Tool” and other side grounded, as figure
4-4-1
In Diagnostics(Alt-7), Digitize led lit when engraving bit touch probe tool. That
means good physical connection.
Probe tool height is near 20mm
but may vary due to workmanship.
Please measure it before auto tool zero.
