ARGENTO E-MOBILITY Active Bike - Technical Data Sheet; Active Bike Technical Specifications

27
10. Technical data sheet
General information
Active Bike Active Sport
Frame aluminium alloy aluminium alloy
Sunspensions - front and rear
Speed L1: ≤ 6km/h
L2: ≤ 20km/h
L3: ≤ 25km/h
(Max speed) *
L1: < 6km/h
L2: ≤ 15km/h
L3: ≤ 20km/h
L4: ≤ 25km/h
(max speed)*
Maximum slope ** 21% 30%
Brakes Front and rear disc brakes Electronic front brake and
rear disc brake
Tyres Size: 20" front and 16" rear
with inner tube
Pressure: 40psi/2.8bar
Size: front and rear 10”
tubeless
Pressure: 44psi/3bar
Maximum load 120 kg 120 kg
Rider Check the current legislation in your country
Operating temperature -5 °C/ 45 °C -5 °C/ 45 °C
Protection level IPX4 IP55
Charging time approx. 6 hours approx. 7 hours
Autonomy** up to 35km up to 80km
Electrical system
Rated power of motor 0.35kW; 350W Brushless 0.5kW; 500W Brushless
Maximum power of motor 0.42kW; 420W 1kW; 1000W
Display LED Built-in LED
Battery 36V 10.4Ah 374Wh 54V 12.5Ah 675Wh
Low voltage protection 31V ±0.5V 37.5V ±0.5V
KERS Yes Yes
Lights Front and rear LEDs Front, rear and lateral LEDs
Features - Sensor-activated direction
indicators
Dimensions and weight
Net weight 18.7 kg 24 kg
Gross weight 23 kg 30 kg
Open item dimensions 1650 x 600 x 1180mm 1307 x 520 x 1275mm
Closed item dimensions 1650 x 230 x 735mm 1307 x 520 x 560mm
Packaging dimensions 1405 x 230 x 580mm 1280 x 285 x 785mm
* Always respect the highway code and the regulations in force in the country where the electric
scooter is used.
** Subject to variations based on the rider's weight, on the road conditions and on the temperature.
