Product description Product code EAN code
Argento E-Bike MiniMad
AR-BI-220014 8052679456093
General information
Display LCD - CDC13-BT
Motor Bafang 36V 250W brushless - rear
Battery Li-Ion 36V 10.4Ah 374Wh - external and removable
Brakes Front and rear mechanical disc brakes - brake levers with cut-o sensor
Gear change Shimano 7 gears (1x7) - rear derailleur
Drive chain - 7 speed
Wheels 20” front and rear
Lights Front and rear LEDs
Frame aluminium 6061 - folding
Battery charger Input: AC 100V-240V 1.8A (Max) - Output: DC 42V 2.0A (Max)
Maximum load supported by E-bike 100 kg
Weight of E-bike 25 kg~
Full speed 25km/h
5. Assembly
Carefully remove the bike from the packaging* and remove the protective material taking care not to damage the relevant
aesthetic parts or force the cables and pre-assembled components.
*The bike must be removed from the packaging by two adults to ensure that it is not damaged and avoid the risk of injury
and/or crushing.
Positioning the handlebar stem
Raise the handlebar stem until it is vertical; tighten the handlebar stem using the locking device indicated by the letter A.
