8
EN
●
Deoxidized annealed copper tube for refrigerant tubing connecting the units of the system; it has to be insulated with
foamed polyethylene (min. thickness 8mm).
●
PVC pipe for condensate drain pipe (ø int.18mm) in length suitable to let the condensate flow into the outside drainage.
●
Anti-freeze oil for flare connections (about 30g.).
●
Electric wire: use insulated copper wires of type and size as shown at paragraph “WIRES’ SIZE AND DELAYED FUSE”.
Supply power wire A:
Multipolar electric wire; the size of the suggested electric wire is showed on the table. The wire must be Mod.
H07RN-F (according to CEI 20-19 CENELEC HD 22). Make sure the length of the conductors between the fixing
point and the terminals allows the straining of the conductors L, N before that of the grounding.
Connecting wire B (SHIELDED):
Bipolar electric shielded wire; the size of the suggested electric wire is showed on the table. The wires have not
to be lighter than Mod. H05VVC4V5-K (according to CEI 20-20 CENELEC HD21).
Connecting wire C (with ground conductor):
Multipolar electric wire; the size of the suggested electric wire is showed on the table. The wires have not to be
lighter than Mod. H07RN-F (according to CEI 20-19 CENELEC HD22). Make sure the length of the conductors
between the fixing point and the terminals allows the straining of the conductors L, N before that of the grounding.
3 - WIRES’ SIZE AND DELAYED FUSE
4 - ADDITIONAL MATERIAL REQUIRED FOR INSTALLATION (NOT SUPPLIED)
INDOOR UNIT SIZE
NARROW TUBE LARGE TUBE
OUTER DIAMETER MIN. THICKNESS OUTER DIAMETER MIN. THICKNESS
A 6,35 mm 0,8 mm 9,52 mm 0,8 mm
B - C - D 6,35 mm 0,8 mm 12,7 mm 0,8 mm
D (ASI) 9,52 mm 0,8 mm 15,88 mm 1 mm
MODEL
A B C Max. electric input
S ( mm
2
) S ( mm
2
) S ( mm
2
) kW / A
AEI1G80BEMX
2,5 0,75 1,5
3,5 / 15,9 20 A
AEI1G80EMX3PH 3,5 / 5,9 12,5 A
AEI1G110BEMX 4,5 / 20,5 25 A
AEI1G110EMX3PH 4,5 / 7,6 12,5 A
5 - OPERATING LIMITS AND MODELS COMBINATION
■ Cooling Maximum conditions
Outdoor temperature : 43°C D.B.
Room temperature : 32°C D.B. / 23°C W.B.
■ Cooling Minimum conditions
Outdoor temperature : –15°C D.B.
Room temperature : 10°C D.B. / 6°C W.B.
■ Heating Maximum conditions
Outdoor temperature : 24°C D.B. / 18°C W.B.
Room temperature : 27°C D.B.
■ Heating Minimum conditions
Outdoor temperature : –15°C D.B.
Room temperature : 5°C D.B.
OPERATING LIMITS
