Outdoor - Indoor unit combination table - SYSTEM CONFIGURATION
System
type
Outdoor
unit
Combination
n.
Indoor unit port Emix
Emix tank
a bcd
mono G80-110 1 C (A2W) X
A - B - C - D = A2A indoor unit size (see catalogue)
A (A2W) - B (A2W) - C (A2W)= A2W indoor unit size (see catalogue)
A2A = air to air models A2W = air to water models
Power Supply: EMX = 220 - 240 V ~ 50 Hz EMX3PH = 380 - 415 3N ~ 50 Hz
Outdoor - Indoor unit combination table - SYSTEM CONFIGURATION
A2A
A2W
Outdoor - Indoor unit combination table - SYSTEM CONFIGURATION
A2W
A2A
System
type
Outdoor
unit
Combination
n.
Indoor unit port Emix
Emix tank
a bcd
trial G80
2 A (A2W) B A X
3 B (A2W) B A X
4 C (A2W) A A X
trial G110
5 B (A2W) B B X
6 C (A2W) B A X
quadri G80
7 A (A2W) A A A X
8 B (A2W) A A A X
quadri G110
8 B (A2W) A A A X
9 B (A2W) B A A X
10 C (A2W) A A A X
System
type
Outdoor
unit
Combination
n.
Indoor unit port Emix
Emix tank
a bcd
mono G80 11 C X
mono G110
12 D X
13 D X
dual G80
14 B A X
15 B B
dual G110
14 B A X
15 B B X
16 C A X
17 C A X
trial G80
18 AAA X
19 B A A X
trial G110
18 AAA X
19 B A A X
20 B B A
quadri G80 21 A A A A
quadri G110
21 A AAA X
22 B AAA
X = combination with Emix/Emix tank is possible
