3. DIMENSIONAL DATA
700
540
15
470
4 – ø12 holes
116
320
294
Air intake
Air discharge
25510
170
103 57
Narrow tube service valve
ø6.35 (1/4")
Wide tube service valve
ø9.52 (3/8")
ø12.7 (1/2")
7000/9000 BTU/h
12000 BTU/h
Unit : mm
12
