Argo CHIC SILVER - Page 17

17
V 06/19
HOW TO INSTALL THE FAN HEATER
The fan heater must be installed on the wall before use. Do not try to use it without installation. The installation sequence is
listed below:
1. Select a space for installing the appliance (figure 1).
2. Drill two holes on the wall that are suitably sized for inserting the Ø 8 mm Fischer screw plugs. (figure 2) – D=575 mm
3. Insert the Fischer screw plugs into the holes and tighten the screws provided.
NOTE: Tighten the screws securely. Do not insert the screws into the Fischer plugs entirely - leave around 10 mm free.
4. Mount the appliance on the wall (figure 3).
Ensure that the holes on the rear of the appliance are directed towards the two screws, push the fan heater backwards
onto the wall then downwards until it lies in a stable position.
CONTROL PANEL AND LED DISPLAY ON THE APPLIANCE
Figure 1
Figure 2
Figure 3
Fischer
TIMER LED
TEMPERATURE
°C LED
ROOM
TEMPERATURE
DISPLAY
ECO Mode LED
energy saving (1000
W)
COMFORT Mode LED
Maximum heat (2000 W)
WEEKLY
TIMER LED
OPEN WINDOWS
Mode LED
TIMER
BUTTON
ON/OFF BUTTON
F BUTTON
Function selection
