Argo Service Manual Engine System
Ontario Drive & Gear Limited. www.odg.com
PH. (519)- 662-2840 FAX (519)- 662-2421
EN-9
Removing the Engine (FD620D Kawasaki Liquid Cooled OHV)
Accessing the 4 mounting bolts that secure the engine to the power pack frame requires
the power pack frame to be removed from the vehicle. Both engine and transmission can
be removed through the engine access opening using an overhead hoist. You may prefer
to remove the transmission first before lifting engine and frame through the hood area..
2. Locate and remove the engine access cover. Photo EN-3
3. Separate the main wire harness from the nylon clips securing it at the back of the
engine. Photo EN-4
EN-3 EN-4
4. Disconnect the main engine wire harness plug located between engine and transmis-
sion. Photo EN-5
5. Remove the starter cable at the electric starter. Photo EN-6
EN-5 EN-6
1. Perform the servicing procedure, Removing the Battery in section ES of this serv-
ice guide.
