Argo Service Manual Electrical System
Ontario Drive & Gear Limited www.odg.com
PH.(519)- 662-2840 FAX (519)- 662-2421
ES-15
ES-16 ES-17
4. Remove the bolt securing the ground cable to the engine.
5. Remove the rest of the hardware securing the blower housing to the engine.
6. Remove the blower housing. Photo ES-18
7. Remove the flywheel nut and recoil cup. Photo ES-19
ES-18 ES-19
8. Attach a universal puller to the flywheel
and pop the flywheel from the magneto
side of the crank using a socket and
wrench. Photo ES-20
While threading the puller into the flywheel,
tap the end of the bolt occasionally with a
steel hammer. This will aid the process of
popping the flywheel free of the engine
9. Remove the flywheel from the engine.
ES-20
3. Perform the servicing procedure, Removing the Intake Duct, in section DE of this
service guide.
