argon audio TT - Technical Specifications

6
T T M a n u a l
Technical Specifications:
Nominal Speeds 33 1/3 & 45RPM
Speed Variance ±1.5%
Wow and Flutter ≤0.15%
Signal to Noise 55dB
Down force Range 3.0-6.0g
Effective Tonearm Length 8.6” (218.5mm)
Overhang 0.73in
Power Consumption 5W
Outboard Power Supply 12V/ 500mA AC-DC
Dimensions (W x H x D) 415 x 340 x 148mm
Weight 6.2kgs
Technical Specifications for stylus: AT-3600L (audio-technica)
Frequency response 20Hz-20kHz
Recommended load resistance 47kohms
Channel balance ＜2.5dB
Amplifier connection MM - input
Channel separation ＞18dB
Recommended tracking force 3.5±0.5g
Output voltage 2.5mV
Weight 5g
