Argos 2274951 - Page 5

4
Assembly Instructions
Step 1
Drawer assembly x 3
a: Insert two small locking
nuts J into drawer wrap
0.
Make sure the ‘arrow’ on
J฀is pointing towards the
hole in the edge of 0.
b: Screw 24mm locking
screws H into holes
shown on back of drawer
front !.
Make sure 24mm locking
screws H are tightened
right up against drawer
front !.
c: Slide drawer base 9
into grooves shown on
drawer wrap 0.
H
10
J
J
11
H
H
H
a:
b
10
c:
11
9 a/b
