Assembly Instructions
Step 1 - continued
Attaching runners
d: Turn the drawer wrap
assembly over and push
onto the drawer front !.
Use a phillips or flatblade
screwdriver, that is a good
fit to turn 24mm locking
srew I as far as it will go
- more than 1/2 turn.
H
d
I
e:
11
T
11
B
B
Step 2
a: Slide top of runners R
foreward and fix on right side
2 as shown using 10mm
fixing screw drawer E.
Finished
front edge
a:
R
R
R
R
E
E
E
E
2
2
I
e: Fix drawer handle T
onto drawer front ! using
30mm screw B.
Turn over drawer and slide
drawerbasesupports U
in corner as shown and fix
them, using the attached
screws.
U
U
To Next Page
