6
Assembly Instructions
b
a:
StepStep 2 - continued
b: Slide top of runners R
back.
Fix through 3rd hole of
runner R and pre-drilled
holes of right side 2 using
10mm fixing screw drawer
E.
Fix through 1st and 7th
hole of runners R using
15mm screw O.
Note: there are no pre-
drilled holes for 15mm
screw O.
Repeat a and b on upright
small 6.
Step 3
Insert fittings
a: Screw 24mm locking
screw H into right side
2.
Note: Insert 24mm
locking screw H as far as
shown.
Do not over tighten.
Screw hinge back P onto
right side 2.
H
2
b: Attach hanger rail
support M using 12.5mm
screw F onto right side
2.
2
P
P
P
P
H
H
H
H
H
H
H
H
P
H
M
F
2
2
H
M
2
F
Finished
front edge
R
R
R
E
E
E
3
O
O
O
O
O
O
b
3
R
E
OO
Warning: Do not use an electric screwdriver to attach the
hinges as this can weaken the fixing.
