Assembly Instructions
Place the large divider
5
onto the bottom
9
.
Push cams
Ca
into the
holes indicated on the
large divider
5
. Arrows
pointing towards the
bottom
9
.
Turn the cams
Ca
to the
right to x the large
divider
5
.
Step 1.15
Screw the bolts
Cb
into
the holes indicated on the
bottom
9
.
Step 1.16
Place the bottom
9
and the back rail
11
onto the small
divider
6
.
Push cams
Ca
into
the holes indicated
on the small divider
6
. Arrows pointing
towards the bottom
9
and the back rail
11
.
Turn the cams
Ca
to the
right to x bottom
9
and
the back rail
11
.
Step 1.17
350264-11
10
Ca
ø15 x 10.5mm Cam x
4
Ca
ø15 x 10.5mm Cam x
3
Cb
ø5 x 8, cc34mm Bolt x 3
Ca
Ca
Ca
Cb
Cb
Cb
Ca
Ca
Ca
Ca
11
6
9
9
5
9
