Argos 2587356 - Page 12

Assembly Instructions
Place the sides
2
and
3
onto the bottom 9 and
the back rail
11
.
Push cams
Ca
into the
holes indicated on the
bottom
9
and the back
rail
11
. Arrows pointing
towards the sides
2
/
3
.
Turn the cams
Ca
to the
right to x the sides
2
and
3
.
Step 1.18
Place the top
1
onto the
sides
2
and
3
.
Push cams
Ca
into the
holes indicated on the
sides
2
and
3
.
Arrows pointing towards
the top
1
.
Turn the cams
Ca
to the
right to x the top
1
.
Step 1.19
350264-12
11
Ca
ø15 x 10.5mm Cam x
9
Ca
Ca
1
Ca
ø15 x 10.5mm Cam x
8
2
Ca
Ca
11
Ca
Ca
Ca
Ca
Ca
Ca
Ca
9
2
Ca
5
3
