Argos 2587356 - Page 6

Assembly Instructions
Knock the dowels
Aa
into
the holes indicated on
the sides
2
and
3
using a
small
hammer.
Screw the bolts
Cb
into
the holes indicated on
the sides
2
and
3
.
Step 1.2
Fix the Crossplates
Mc
to the sides
2
and
3
using the pre-mounted
screws.
Note the details.
Position the Crossplates
Mc
exactly as shown.
Fix the support for
hangerrail
Fl
onto the
left hand side
2
using
screw
Bo
.
Step 1.3
350264-06
5
Cb
ø5 x 8, cc34mm Bolt x 8
6 ø7.8 x 40mm Wooden dowel x
Aa
Cb
Cb
Aa
Aa
Aa
Aa
3
2
ø3 x 12mm Screw x
Bo
1
Fl
1
Support for hanger rail - 15mm x
Mc
4
0mm Crossplate x
Cb
Cb
Cb
Cb
Cb
Cb
Aa
Aa
Fl
Bo
3
2
Mc
Mc
Mc
Mc
