Assembly Instructions
Slide the top of the
drawer runners
Sa
backwards. You can
identify the front end of
the drawer runner
Sa
by
the two M4 holes. See
details.
Place the spacers
Nu
as
shown, and x the
front end of the drawer
runners
Sa
to the sides
2
and
3
using screws
Kf
through the holes
number 1 and 7.
See details.
Step 1.4
Slide the top of the
drawer runners
Sa
forwards.
Place the spacers
Nu
as
shown, and x the
back end of the drawer
runners
Sa
to the sides
2
and
3
using screws
Kf
through the holes
indicated.
See details.
Step 1.5
6
350264-07
3
Sa
Kf
Note the hole!
Bottom end of
right hand side
Front end
Sa
Front end
Front end
Sa
4 310 x 17 x 10mm Drawer runner x
Kf
Kf
Kf
Kf
Sa
Sa
Sa
2
2
3
Kf
Kf
Kf
Sa
Kf
Kf
Sa
Kf
Kf
Kf
8
ø5.8 x 19mm Screw x
ø18 x 9mm Spacer x
Nu
8
ø18 x 9mm Spacer x
Nu
4
Kf
4
ø5.8 x 19mm Screw x
Nu
Nu
Nu
Nu
Nu
Nu
Nu
Nu
Hole no. 1
Hole no.
7
Hole no.
7
Hole no. 1
