Argos 2587356 - Page 8

Assembly Instructions
Fix the Crossplates
Mc
to the large divider
5
using the pre-mounted
screws.
Note the details.
Position the Crossplates
Mc
exactly as shown.
Fix the support for
hangerrail
Fl
onto the
large divider
5
using
screw
Bo
.
Step 1.7
Knock the dowels
Aa
into
the holes indicated on
the large divider
5
and
the
small divider
6
using
a small hammer.
Step 1.6
350264-08
7
9 ø7.8 x 40mm Wooden dowel x
Aa
ø3 x 12mm Screw x
Bo
1
Fl
1
Support for hanger rail - 15mm x
Mc
2
0mm Crossplate x
5
6
5
Bo
Fl
Aa
Aa
Aa
Aa
Aa
Aa
Aa
Aa
Aa
Mc
Mc
