Please check you have all the fittings listed below
Note: The quantities below are the correct amount to complete the assembly. In some cases
more fittings may be supplied than are required.
Components - Fittings
If you need help or have damaged or missing parts, please visit www.argos-support.co.uk
or email: Help@ClickSpares.co.uk (quoting your original order number)
Alternatively, call the Spares Helpline on: 0370 112 1928.
For any other queries please contact the Customer Helpline on: 0345 640 2020
3
A
Wooden dowel
(F22) x 8
B
Metal dowel
(F901) x 14
C
D
Large locking cam
nut
(F900) x 8
E
Small locking cam
nut
(F3) x 6
F
IG
40mm Screw
(F910) x 16
H
NL
O
M
25mm
Screw (F50) x 3
J
Ruler - Use this ruler to help correctly identify the screws
mm 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170
Handle (F631) x 3
Nail
(F51) x 11
Knock-in Peg (F171GY) x 12
Wedgefix (F639) x 6
Drawer runner (F1004) x 6
K
9mm Screw (F73) x 12
9mm Screw (F74) x 6
Plastic Nail
(F91) x 8
Strap
Screw Washer x 2
Overbalance protector kit (F269) x 2
Tools required
Rule
Scissors
Hammer
Eye protection
(when using a
hammer or drill)
Cross-head
screwdriver
Electric drill
(do not use for
fitting screws)
