Argos 758/5432 - Components - Fittings and Tools; Fittings Identification; Required Tools and Aids

Please check you have all the fittings listed below
Components - Fittings
3
If you have damaged or missing components,
call the Customer Helpline: 08456 400800
Note: The quantities below are the correct amount to complete the assembly. In some cases more
fittings may be supplied than are required.
A B C
M6x15mm Allen screw x 8
D E
M6x45mm Allen screw x 21
F
Arc washer-large x 16
G H
J
Nut x 12
L M
N
Plastic plug x 2
A
Arc washer-small x 19
Plastic washer x 16
M6x65mm Allen screw x 7
M8x65mm Allen screw x 8
M6x10mm Allen screw x 82
K
Plastic cap x 4
M6x35mm Allen screw x 4
P
Small allen key x 2
Q
Large allen key x 1
Plastic spacer x 10
0
5
10 15 20 25 30 35 40
45
50
55
60 65 70
75
80 85 90 95 100 105 110 115 120 125 130 135 140 145 150 155 160 165 170
0
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 105 110 115 120 125 130 135 140 145 150
1 2
3
4
5 6
Ruler/tape
measure
Ruler - Use this ruler to help correctly identify the screws
Tools required
