Assembly Instructions
Step 17
Step 18
11
P
Q
D
A
A
A
A
A
A
06
06
06
M
M
N
N
1.
2.
F
F
F
F
F
Fixing wall strap:
Fix wall strap H to top of
product (edge) using
washer I and screw J as
shown.
P
A
Q
D
Hanging doors:
With help, slot door hinges
N onto hinge
plates M and tighten
screws.
N
M
Hinge adjustment:
1- To move doors left or
right, loosen screw shown
and move doors to suit.
Re-tighten screws.
2 - To move doors in or out,
loosen screw shown and
move doors to suit.
Re-tighten screws.
3 - To move doors up or
down, loosen screws
shown and movedoors to
suit. Re-tighten screws.
1.
2.
3.
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400 800
Assemble is complete
Insert wooden dowels
into the runners as shown.
Place drawers onto runners
and slide past dowels
fitted to runners.
Then, with hammer, tap
plastic pins in flush with
drawer side, this is a safety
catch to stop drawer falling
out.
