Components - Fittings
Please check you have all the fittings listed below
If you have damaged or missing components,
call the Customer Helpline: 08456 400 800
Note: The quantities below are the correct amount to complete the assembly. In some cases more
fittings may be supplied than are required.
Ruler - Use this ruler to help correctly identify the screws
0
5
10 15 20 25 30 35 40
45
50
55
60 65 70
75
80 85 90 95 100 105 110 115 120 125 130 135 140 145 150 155 160 165 170
Tools required
Phillips screwdriver
(medium & large)
Eye protection
(when using a
hammer or glue)
Small
hammer
Ruler/tape
measure
A
A
A
D
H
Foot pad 5 X
A
B
8,0 x 30mm Wooden dowel
X 54
C
I
3,5 x 30mm Screw X 48
3,5 x 25mm Screw X 12
3,5 x 40mm Screw X 3
3,5 x 14mm Screw X 25
E
F
Handle X 6
Plastic pin X 6
G
10 x 10 Nail X 35
J
L
Locking nut X 16
M
Hinge plate X 4
Thin hinge plate X 2
N
Hinge X 6
O
Metal dowel X 16
P
Wall strap X 1
Q
R
Washer X 2
Squared washer X 4
