14
3x
3x
3x
Assembly Instructions
Screw 24mm locking
screw A into drawer front
(.
Note: Insert 24mm locking
screw A as far as shown.
Do not over tighten.
Position drawer front (
onto drawer.
Use a screwdriver to turn
locking nuts B clockwise
to lock.
Note: look carefully to the
positions of drawer front (.
Fix drawer handles O onto
drawer front ( using
screw H.
Preparing drawer
Insert locking nuts B into
left drawer side ^ and
right drawer side *.
Make sure the ‘arrow’ on
locking nuts B points
towards the hole in the
edge of left drawer side ^
and right drawer side *.
Put drop of glue g into
the 3 holes of left drawer
side ^ and right drawer
side *.
Attach left drawer side ^
and right drawer side *
onto drawer back &.
Insert drawer bottom $.
Step 17
Step 18
Step 19
A
B
AG
AG
AG
B
B
A
A
B
O
H
H
14
14
16
16
17
17
18
18
19
19
