Step 20
Assembly Instructions
Step 22
a: Position L-bracket N on
top 9 as shown, fix using
screw I.
Note: there is no pre-drilled
hole for screw I.
Use wall plug & parker
screw e to fix on the wall,
please see page ‘Wall
Mounting & Fixings’ for
more information.
b: Before adjusting the
doors, use a spirit level to
check if the base of this
unit is level front-to-back
and side-to-side in the
three positions shown.
Use peg V to square
your furniture. Knock peg
V in, as far as you require,
under the end of the side of
the forniture. Then snap off
flush with the side.
a:
AE
I
N
!
V
V
b:
Assembly is complete.
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos 03456 400 800
AE
I
N
V
V
1
9
16
To Next Page
