Assembling Instruction Sullivan Entry Cabinet 70"
Step 4 - Install Small Backpanel (4)
Attach Top Backpanel (7)
on Top Shelf (6) and install
these top parts to the cabinet.
Step 5 - Install Top Parts
Insert Hex Screw M6 x 40 (B)
with Ring (A) from outside upper
side, then tight firmly by turning
clock wise using Hex Key (E).
A
B
E
Step 7 - Install Adjustable Shelf (8) and Cushion (9)
F
Insert Hex Screw M6 x 40 (B)
with Ring (A) from bottom and
lower side, then tight firmly
by turning clock wise using
Hex Key (E).
Insert Hex Screw M6 x 40 (B)
with Ring (A) from upper side.
B
A
E
B
A
E
8
Insert Small Backpanel (4) into
the groove and push to the side.
4
7
6
Step 6 - Install Left Side Panel (2L)
2L
Attach Left Side Panel (2L) to the cabinet.
9
Insert Shelf Support (F). Install Adjustable Shelf (8) and Cushion (9).
Unscrew the two Hex Screw M6
x 50 and place on the cabinet.
Reinstall the two Hex Screw M6
x 50 (C) with Ring (A) from top
parts.
C
A
E
To Next Page
