The wood in this collection lives and breathes with the seasons, often displaying slight movement due to changes in temperature and humidity. To retain the organic luster of the wood, care for
your furniture with annual applications of Fiddes® Wax.
Wood products have a lacquer coat and a wax finish applied to the surface. Before application, ensure that the surface is clean and dry. Apply Fiddes® Wax to the surface in small sections
following the grain. This wax is quick drying and can be buffed after it dries for a desired sheen.
D
E
B
C
1. Attach one of the mounting brackets near the top back edge of
the furniture piece by inserting the shorter screws.
2. Determine the final position of the furniture piece. Mark location
on the wall pproximately 2" below the bracket mounted to the
back of the furniture.
3. Drill a starter hole into the wall stud. If wall stud is not available,
drill a hole into the wall and insert plastic anchor. Gently tap the
anchor until the flange of the anchor is flush with the wall.
4. Attach the second bracket by inserting the longer screw through
the bracket and into the wall.
5. Place the furniture so the bracket on the back edge is in line with
the bracket on the wall.
6. Lace one end of the nylon restraint strap down through each
bracket. Bring both ends together and slide the beaded end until
it snap locks into the keyhole slot.
7. To double lock, return the beaded end back through the
keyholes as shown.
8. Check to make sure the strap is securely laced and locked to the
brackets.
ASSEMBLING INSTRUCTION TREMONT MODULAR 20" DR BASE
C = Phillips screws M4x30mm 4Pcs
D = Phillips screws M4x20mm 4Pcs
TOOLS NEEDED
Phillips head screwdriver (not provided)
HARDWARE LIST
A = Plastic brackets 4Pcs
B = Restraint straps 2Pcs
E = Plastic anchors 4Pcs
