ASSEMBLY
OPERATOR’S POSITION (See Fig. 1)
When right or left hand is mentioned in this manual, it
means when you are in the operating position (standing
behind tiller handles).
Your new tiller has been assembled at the factory with exception of those parts left unassembled for shipping purposes.
To ensure safe and proper operation of your tiller all parts and hardware you assemble must be tightened securely. Use
the correct tools as necessary ensure proper tightness.
TOOLS REQUIRED FOR ASSEMBLY
A socket wrench set will make assembly easier. Standard
wrench sizes are listed.
(1) Utility Knife
(1) Screwdriver
(2) 1/2" Wrenches
OPERATOR'S POSITION
RIGHT
FRONT
LEFT
overhead_views_8
Fig. 1
(6) Lock Washers 5/16
(6) Hex Nuts 5/16-18
(4) Hex Bolts 5/16-18 x 1-1/4
(2) Hex Bolts 5/16-18 x 1
(4) Washers 3/8 x 7/8 x 14
CONTENTS OF HARDWARE PACK
