GB - 10
1. Engine/Blade Control
2. Wheel Drive Control (911193, 194)
3. Adjustable and Folding Handlebars
4. Swivel Wheel Lock (911194)
5. Grass Bag
6. Rear Door
7. Fuel Tank and Cap
8. Height Adjustment Pins (911194)
9. Muffler and Muffler Guard
10. Oil Fill/Dipstick
11. Cutting Height Levers (2 Rear Wheel
Adjusters, 2 Front Wheel Adjusters)
12. Primer Bulb (911192, 193, 194)
13. Air Filter
14. Side Discharge Cover
15. Side Discharge Deflector
16. Mulchmaster™ Plug
17. Handlebar Adjustment Holes
18. Recoil Starter Handle
19. Speed Control Rod (911193, 194)
CONTROLS AND FEATURES
Figure 4
1
7
15
16
1
2
4
3
5
6
7
13
9
8
14
10
11
18
19
3
6
10
13
9
11
12
11
14
11
17
18
12
5
OM3195
2
7
19
8
17
