Ariens Max Zoom 2560 User Manual

GB - 11
1. Fuel Tanks and Caps
2. Steering Levers
3. Hydraulic Oil Reservoir
4. Ignition Switch
5. Hour Meter
6.
Throttle Lever
7. Choke Control
8. Power Take Off (PTO) Switch
9. Battery
10. Fuel Shut Off Valve
11. Mower Lift Pedal
12. Mower Deck
13. Mower Lift Lock
14. Seat Adjustment Lever
15. Parking Brake
16. Bypass Valve Lever
CONTROLS AND FEATURES
16
Figure 4
1
2
4
5
7
8
3
9
10
11
12
13
14
15
6
OF4035
OF4095
OM4090
OM4085
