Owner/Operator Manual

Models

915061 - 1434

915063 - 1540

915069 - 1534

915316 - 1434

MINI-ZOOM

00346700A 1/05

Supersedes 00346700

Printed in USA

Transfer

model &

serial number

label from

product reg-

istration here.

Coller l’autocollant du

modèle et du numéro de

série dans cet encadré.

Transferir aquí la etiqueta del

modelo y número de serie

del registro del producto.

ENGLISH

FRANÇAIS

ESPAÑOL

Questions and Answers:

R
Rebecca WardAug 3, 2025
Why won't my Ariens Mini-Zoom 915069-1534 engine crank or start?
- A
  Ashley ScottAug 4, 2025
  Several factors can prevent your Ariens Lawn Mower engine from cranking or starting: * The safety interlock system may not be engaged or could be faulty. Check the safety interlock system. * The fuel tank might be empty; refill it. * The battery could be discharged; charge it. * There might be a poor connection between the battery and cables; tighten the cables or clean them. * The spark plug wires could be loose, or the spark plugs may be faulty; connect the wires or replace the spark plugs.
C
Christopher GriffinAug 8, 2025
Why does my Ariens Mini-Zoom 915069-1534 engine run rough?
- S
  sarahtownsendAug 8, 2025
  An Ariens Lawn Mower engine might run roughly due to: * The choke being engaged; disengage it. * A plugged air filter cartridge; clean or replace it.
M
Mitchell RobinsonAug 12, 2025
What to do if my Ariens Lawn Mower engine overheats?
- C
  Cody FoleyAug 12, 2025
  If your Ariens Lawn Mower engine overheats, check the following: * Ensure the engine oil level is sufficient; add oil if needed. * The cooling system may be plugged; clean it.
E
Eric RobertsonAug 16, 2025
What to do if my Ariens Mini-Zoom 915069-1534 Lawn Mower does not move with engine running when using steering levers?
- H
  Howard McgrathAug 17, 2025
  If your Ariens Lawn Mower doesn't move when using the steering levers with the engine running: * Check if the transmission bypass lever is engaged; disengage it. * The hydrostatic belt may be faulty; replace it.
S
Shannon ThomasAug 21, 2025
How to fix Ariens Lawn Mower that does not travel in a straight line?
- A
  andrademeredithAug 21, 2025
  If your Ariens Lawn Mower isn't traveling in a straight line: * Check and correct the tire pressure. * Adjust the steering levers.
B
Brian TaylorAug 26, 2025
How to improve poor cutting quality of Ariens Mini-Zoom 915069-1534?
- S
  Steven ChavezAug 26, 2025
  To address poor cutting quality with your Ariens Lawn Mower: * Level and adjust the pitch of the mower deck. * Sharpen or replace dull or faulty mower blades.
C
cooperbrittanyAug 29, 2025
What to do if my Ariens Mini-Zoom 915069-1534 PTO or mower blades do not engage or shut off?
- L
  lori60Aug 30, 2025
  If the PTO or mower blades on your Ariens Lawn Mower fail to engage or shut off, consider these potential causes: * Ensure the operator presence switch is depressed by sitting on the seat. * The electric clutch connector may be loose or disconnected; connect it. * The PTO belt might be faulty; replace it.
